Horizontal Laboratory Autoclave F-HLA101

Home Autoclave Horizontal Laboratory Autoclave Horizontal Laboratory Autoclave F-HLA101

Horizontal Laboratory Autoclave F-HLA101 is a 300 L capacited top loading compact and robust high pressure steam sterilizing unit. The complete leak proof chamber provides efficient sterilization process resulting in destruction of all living organisms due to the high pressure and temperature maintained. It is equipped with two pressure gauges to indicate inner and interlayer pressure with interlock device for safety.

Specification Features Applications Download Catalog

Capacity	300 L
Sterilization Temperature	134 °C
Sterilization Pressure	0.22 Mpa
Timer Range	0 - 99 minutes
Heat Average	≤ ± 1 ℃
Chamber Dimensions ( Φ × D )	600 × 1200 mm
Product Dimension ( L × W × H )	480 × 480 × 940 mm
Net Weight	290 kg
Gross Weight	365 kg
Power Supply	12 kW / AC 380 V 50 Hz

Digital LCD display to monitor working status and parameters

Working pressure : 0.22 MPa

Working temperature : 134 ?

Automated drying function

Safe door lock system ensuring safety / protection during sterilization

Automatic power cut off with alarm with low water levels indication

Built in two pressure gages to indicate inner and interlayer pressure

It is suitable for medical, laboratory, microbiological, clinical use and to sterile the waste before discarding.

F-HLA101
