Horizontal Laboratory Autoclave F-HLA102

Home Autoclave Horizontal Laboratory Autoclave Horizontal Laboratory Autoclave F-HLA102

Horizontal Laboratory Autoclave F-HLA102 is a 500 L capacited top loading compact and robust high pressure steam sterilizing unit. The complete leak proof chamber provides efficient sterilization process resulting in destruction of all living organisms due to the high pressure and temperature maintained. It is equipped with two pressure gauges to indicate inner and interlayer pressure with interlock device for safety.

Specification Features Applications Download Catalog

Capacity	500 L
Sterilization Temperature	134 °C
Sterilization Pressure	0.22 Mpa
Timer Range	0 - 99 minutes
Heat Average	≤ ± 1 ℃
Product Dimension ( L × W × H )	500 × 510 × 1010 mm
Overall Size ( L × W × H )	650 × 650 × 1200 mm
Net Weight	375 kg
Gross Weight	450 kg
Power Supply	16 kW / AC 220 V 50 Hz

Digital LCD display to monitor working status and parameters

Working pressure : 0.22 MPa

Working temperature : 134 ?

Automated drying function

Safe door lock system ensuring safety / protection during sterilization

Automatic power cut off with alarm with low water levels indication

Built in two pressure gages to indicate inner and interlayer pressure

It is suitable for medical, laboratory, microbiological, clinical use and to sterile the waste before discarding.

F-HLA102
