Description :

Features :

Programmed and manual identification of lanes and bands supports the most appropriate way to analyse the results according to the sample
It has the reliable quality Lens like F1.2 motorized lens with 6x optical zoom
The software program has the ability for the automatic focusing of samples by algorithm, evading the error of humanoid decision
The Filter System has 590nm Standard filter
The Light Source used in this device is White light LED*2
The Sample trays provided in the instruments are UV
Transilluminator with Standard 302nm and White light plate
Automatically recognize 8-bit, 10-bit, 12-bit, 14-bit and 16-bit images
The samples are UV Protected using a UV Protection Shield
The image acquisition and analysis software provide multi-language operation interface
To make the user to operate conveniently
It has many features as Add, delete, adjust the lanes and bands
Automatically and manually calculate the density, integral and peak value of each band in the lanes
It can calculate of the optical density, molecular weight and mobility of the bands more accurate
Appropriate for the calculation and quantifiable examination of the optical density for various samples
Study information can be directly output to excel files

Applications:

DNA/RNA detection Various fluorescent dyes, such as: EtBr, Gel Red, Gel Green, SYBR ™ Gold, SYBR ™ Green, SYBR ™ Safe, Texas Red labelled DNA / RNA detection; Protein detection Coomassie brilliant blue, silver-stained glue and fluorescent dyes, such as: Sypro ™ Red, Deep Purple and Pro-Q Diamond, labelling glue / membrane / chip, etc.

Optional Accessories:

Sample Tray Trans-Blue
